600 polar


quieter. cleaner. more economical.

Representative of a new generation. Pioneer and milestone. Dream machine. This is what can happen when a manufacturer develops a snow groomer in close cooperation with its customers. With the PistenBully 600 Polar, we have jointly succeeded in setting new standards. In terms of power and performance. In efficiency, operation and comfort. The PistenBully 600 Polar is lighter than any other in its class. And more environmentally friendly.

The PistenBully 600 Polar is more than just a normal snow groomer. It stands not only for perfect slopes, but also for sustainable and efficient slope management at the very highest level.

PistenBully 600 Polar pushes snow with the blade.
The visuals are convincing. But what is really sensational is the operation with the new joystick. This is a real innovation! Even a novice can quickly get to grips with operating the blade and milling at the same time.
Leo Schuster, Technical Manager Oberstdorf Kleinwalsertal Bergbahnen, Germany

Showroom
PistenBully 600 Polar: side view
The chains of the PistenBully 600 Polar for any application.

Chains for every application

As flexible as a Swiss army knife, our undercarriage in combination with the chain can be adapted to all customer requirements and thus offers the perfect solution for every application, regardless of what is important: thrust, climbing ability, turning ability, transport or heavy additional equipment.

Combination equipment rack

The combination equipment carrier is the "one for all" solution. Thanks to the SlopeTracer, it can follow the slope both parallel and depending on the ground. The Autotracer provides additional lateral support and perfect tracking. Thus another must-have for the perfect slope.

The quick-change system of the PistenBully 600 Polar.

Quick-change system

Packed with stronger cylinders, load holding valves and pipe breakage protection, the new quick-change system enables the highest attachment torques required for snow canon transport or pipe maintenance. Of course, the unrestricted mobility is still maintained.

The special Polar shield of the PistenBully 600 Polar...

AllWayBlade Polar

Wider, higher and stronger best describe the Polar blade. Designed for our most powerful PistenBully, it guarantees optimum grooming results and durability in the toughest applications or when transporting snow canons thanks to the standard mounting bracket.

The driver's cab of the PistenBully 600 Polar.

Driver's cab

The driver is the center of attention. This guiding principle is realized in our cab with comfort, ergonomics and intuitive operation. Thanks to generous glazing, perfect arrangement and ideal LED illumination, visibility is perfect, especially at night.

 Cockpit PistenBully 600 Polar.
The control unit of the cockpit of the PistenBully 600 Polar.

Control unit

For a steady hand and safe handling in every driving situation: driver's seat, armrest and joystick are firmly connected. An ergonomic and comfortable unit. Individually adjustable to the driver. Enables fatigue-free operation, even when driving in rough terrain.

The high-quality interior trim in the cockpit of the PistenBully 600 Polar

Interior

High quality and easy to clean interior trim. New floor assembly. Both with innovative thermal insulation and significantly improved soundproofing, making the PistenBully 600 Polar quieter than ever before. Optimized ventilation in the center console ensures a perfect interior climate - with comfort automatic air conditioning for the first time on request, plus plenty of space and freedom of movement.

Joystick PistenBully 600 Polar

Joystick

Ergonomic and freely movable in all directions. For intuitive control. The joystick's four axes allow four simultaneous movements of the blade. And proportional control of the attachments. All with just one hand.


SNOWsat iX

SNOWsat

SNOWsat snow depth measurement provides a precise overview of the snow situation in the ski area. Only if you know the snow depths everywhere on the slopes can you move snow in a targeted manner. The result: perfect slopes for your guests every day, increased productivity, enormous cost savings, careful use of resources and increased work and operational safety.


But: SNOWsat is more than just snow depth measurement. Discover all SNOWsat solutions!

Das iTerminal im Cockpit des PistenBully 600 Polar.

iTerminal

10-inch display with touch control. Clear and easy to use. All active vehicle parts are highlighted in color. With quick navigation option via symbols. Completely prepared for SNOWsat.

Halblenkrad des PistenBully

Half-steering wheel

Precise steering: The semi-steering wheel is infinitely adjustable side-to-side and fits comfortably in the hand. The driver effortlessly steers the PistenBully and finds the most important functions directly in the steering.

Alternative Sticksteuerung
Alternative

Sticks

As an option to the steering wheel: Stick control for direct handling and steering. A thumb dial potentiometer regulates travel speed.

Der kompakte Motor des PistenBully 600 Polar.
Larger tank capacity of the PistenBully 600 Polar.

Larger tank volume

Significantly more power and torque than its predecessor despite lower fuel consumption. Long range thanks to larger tank volume (300 l) for efficient and economical operation.

The diesel particulate filter of the PistenBully 600 Polar.

Diesel particulate filter

Environmentally friendly pioneer: With the clean 6-cylinder engine with 520 hp including diesel particulate filter, the PistenBully 600 Polar was the first snow groomer in the world to meet EU Stage V.

The compact engine with simple structure of the PistenBully 600 Polar.

Compact engine

Compact engine with simple design. Fewer complex components and improved access. Thus clear, easy to maintain and less prone to faults and errors.

A freshly groomed slope.

Assistance systems

Assistenzsystem des PistenBully 600 W: AutoTracer
MAXIMUM TRACKING STABILITY

AutoTracer

Rear implement carrier with intelligent, active steering assistance. Possible in both rigid position (fixed) and floating position (relieved). When activated the tiller follows the 600W in the same curve radius. Automatic countersteering on side slopes. For automatic support and relief of the driver!

Assistenzsystem des PistenBully 600 W: SlopeTracer
IDEAL GROUND FOLLOWING

SlopeTracer

Intelligent control of the rear implement carrier. Can be used like a parallel tool carrier via software. Ensures perfect ground adaptation of the tiller in hilly terrain and automatically adjusts the milling depth. The patented SlopeTracer simplifies operation and enables very large movement radii.

Assistenzsystem des PistenBully 800: Schneetiefenmessunng
RESOURCE-CONSERVING SNOW MANAGEMENT

SNOWsat
snow depth measurement

The high-precision snow depth measurement helps the operator detect slope areas with small amounts of snow and identify snow reserves – under, in front of and on both sides of the vehicle. This way snow can be pushed with precision and maximum quality can be achieved for the slope structure. Increases productivity while conserving resources and helping to preserve the environment.

Technical data

TypeCummins X 12
Number of cylinders6
Displacement11.8 l / 11,800 cm³
Performance according to ECE382 kW / 520 PS
max. torque2,375 Nm @ 1,200 U/min
Tank capacity300 l
Fuel consumptionfrom 19.5 l/h
Tank capacity DEF (AdBlue)38 l
Emission standardEU Stage V and EPA Tier 4F (USA)
Traction drive pump175 cm³
Traction drives125 cm³
Milling drive105 cm³
Technische Daten des PistenBully 600 und 600 Polar.
TypeCummins X 12
Number of cylinders6
Displacement11.8 l / 11,800 cc
Performance according to ECE512 hp
max. torque2,375 Nm @ 1,200 rpm
Tank capacity79 gal
Fuel consumptionfrom 5.15 gal/h
Tank capacity DEF (AdBlue)10 gal
Emission standardEU Stage V and EPA Tier 4F (USA)
Traction drive pump175 cc
Traction drives125 cc
Milling drive105 cc
Equipment

Transmission, Chassis & Wheels

  • Optimized transfer case with less noise and vibrations
  • Exclusively drawn axles for improved driving behavior
  • Shorter axles for better accessibility to the drive components
  • Reinforced rocker arm and wheel bearing due to larger tapered roller bearings
  • QuickAdjust for quick adjustment of the chassis via gearing
  • Individual axle loads and spring characteristics for improved ride comfort (solo/winch)
  • More running smoothness and low pitching behavior thanks to damping composite plain bearings
  • Magnum star wheel
  • Fixed wheels
  • Functional mudguards against snow ejection

Hydraulics and working hydraulics

  • Electro-hydraulic brake
  • New pump transfer gearbox tilts the travel pumps outward by 5
  • Optimized accessibility
  • 20% higher liter output than the predecessor
  • Optimized control for better efficiency
  • High pressure filter
  • Calibrated valves with identical response in all vehicles
  • Best performance values for speed and responsiveness
  • Individually adjustable valve characteristics
  • All functions can be controlled proportionally independently of each other
  • Common parts (e.g. proportional valves and solenoid coils)

Cabin

  • High-end sound system precisely matched to the vehicle
  • Rear camera color
  • DAB+ radio
  • Bluetooth hands-free kit
  • Connections: USB and audio in
  • Comfort driver's seat

Lighting

  • LED light package
  • LED SideFinder lights integrated in the support frame
  • LED TillerFlap lights
  • LED BladeFlap lights
  • Additional LED turn signals and tail lights integrated in the support frame

Electronics and batteries

  • Simple onboard diagnostics with error output in plain text
  • Automatic temperature compensation with cold run protection of the components
  • Maintenance-free batteries with higher cold start current
  • Service-friendly due to reduced variety of parts

Technology and engine

  • Auxiliary tank 120 l
  • Trailer hitch
  • High pressure connection for hydraulic front equipment
  • Feed pressure reduction
  • Stick control with power potentiometer for temporary increase of motor speed
  • Hydraulic oil preheating

Cabin and comfort

  • Suspender belt
  • Parking heater
  • Automatic air conditioning
  • Premium sound package with Alpine subwoofer and amplifier
